Compression Latch Non-Locking 35.0 35.0 Chrome Plated Zinc Alloy
Compression Latch with Wing Knob and is non-locking. Ideal for applications that require better sealing. 6mm pre-set compression.
Essentra part number
20072230
Cutout Dimensions
22.2 x 20.2 mm
Cam Length
49.0mm
Colour
Natural
Material
Die Cast Zinc Alloy
Grip Range
35.0 mm
Head Diameter
56.0mm
Head Height
26.0mm
Maximum Grip
35.0mm
Coating
Chrome Plated
Locking Mechanism
Non-Locking
Housing Height
32.0mm
Compression
6.0 mm
Key Type
No Key
