Centre pull-tab for easy fit and removal. Excellent protection from damage, dirt, moisture and corrosion during production, storage and transportation.
Centre pull-tab for easy fit and removal. Excellent protection from damage, dirt, moisture and corrosion during production, storage and transportation.
Item Code | Colour | Minimum Plug Diameter | COMPLIANCE ROHS | COMPLIANCE REACH | Variant Description | Height Under Flange | Pull Direction | Title | Thread Size | Material | Overall Diameter | Overall Height | Maximum Plug Diameter | Request Quote |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Red | 6.2mm | Y | Y | This red LDPE centre pull tab plug has a tapered design to fit diameter holes ranging from 6.2 to 7.7 mm. The central pull tab allows an easy fit and removal | 9.5mm | Trung tâm | Centre Pull Tab Plug 20.5 mm 6.2 mm LDPE - PIR Red | 5/16 in; M8 | LDPE - PIR | 11.1mm | 20.5mm | 7.7mm | ||
Red | 9.5mm | Y | Y | This red LDPE centre pull tab plug has a tapered design to fit diameter holes ranging from 9.5 to 10.8 mm. The central pull tab allows an easy fit and removal | 9.5mm | Trung tâm | Centre Pull Tab Plug 20.5 mm 9.5 mm LDPE - PIR Red | 3/8 in | LDPE - PIR | 14.0mm | 20.5mm | 10.8mm | ||
Red | 22.5mm | Y | Y | Designed for easy removal and installation. Features a central pull tab that simplifies handling. Affords superior protection against damage, dirt, moisture, and corrosion throughout the stages of production, storage, and transportation. | - | Trung tâm | Centre Pull Tab Plug 29.0 mm 22.5 mm LDPE - PIR Red | - | LDPE - PIR | 28.9mm | 29.0mm | 25.5mm | ||
Red | 8.4mm | Y | Y | This red LDPE centre pull tab plug has a tapered design to fit diameter holes ranging from 8.4 to 10 mm. The central pull tab allows an easy fit and removal | 9.5mm | Trung tâm | Centre Pull Tab Plug 20.5 mm 8.4 mm LDPE - PIR Red | 7/16 in; 1/8 in; M10 | LDPE - PIR | 13.5mm | 20.5mm | 10.0mm | ||
Red | 14.2mm | Y | Y | This red LDPE centre pull tab plug has a tapered design to fit diameter holes ranging from 14.2 to 16 mm. The central pull tab allows an easy fit and removal. | 11.9mm | Trung tâm | Centre Pull Tab Plug 22.9 mm 14.2 mm LDPE Red | 5/8 in; 3/8 in; M16 | LDPE | 19.0mm | 22.9mm | 16.0mm | ||
Red | 16.4mm | Y | Y | Designed for easy removal and installation. Features a central pull tab that simplifies handling. Affords superior protection against damage, dirt, moisture, and corrosion throughout the stages of production, storage, and transportation. | - | Trung tâm | Centre Pull Tab Plug 23.5 mm 16.4 mm LDPE - PIR Red | - | LDPE - PIR | 22.2mm | 23.5mm | 18.3mm | ||
Red | 17.8mm | Y | Y | This red LDPE centre pull tab plug has a tapered design to fit diameter holes ranging from 17.8 to 20 mm. The central pull tab allows an easy fit and removal. | 13.7mm | Trung tâm | Centre Pull Tab Plug 24.5 mm 17.8 mm LDPE - PIR Red | 13/16 in; 1/2 in | LDPE - PIR | 23.8mm | 24.5mm | 20.0mm | ||
Red | 48.2mm | Y | Y | Designed for easy removal and installation. Features a central pull tab that simplifies handling. Affords superior protection against damage, dirt, moisture, and corrosion throughout the stages of production, storage, and transportation. | - | Trung tâm | Centre Pull Tab Plug 26.4 mm 48.2 mm LDPE - PIR Red | - | LDPE - PIR | 57.1mm | 26.4mm | 52.7mm | ||
Red | 11.7mm | Y | Y | Designed for easy removal and installation. Features a central pull tab that simplifies handling. Affords superior protection against damage, dirt, moisture, and corrosion throughout the stages of production, storage, and transportation. | - | Trung tâm | Centre Pull Tab Plug 22.0 mm 11.7 mm LDPE - PIR Red | - | LDPE - PIR | 17.2mm | 22.0mm | 13.7mm | ||
Red | 10.9mm | Y | Y | This red LDPE centre pull tab plug has a tapered design to fit diameter holes ranging from 10.9 to 12.3 mm. The central pull tab allows an easy fit and removal. | 9.5mm | Trung tâm | Centre Pull Tab Plug 20.3 mm 10.9 mm LDPE - PIR Red | 1/2 in; 1/4 in; M12 | LDPE - PIR | 15.9mm | 20.3mm | 12.3mm |
